Command palette and shortcuts
Jump to any screen or model by typing, with Ctrl+K, and look up every keyboard shortcut in eode.
Where: Any screen→Ctrl+K (⌘+K on macOS)
The command palette opens a search box over the page. Type part of a screen or model name and press Enter to go there. Nothing on screen points to it: the shortcut is the only way in.
Open and close the palette
Press Ctrl+K (⌘+K on macOS) on any screen. The box, Search models, screens, or actions…, has the cursor in it, and the model list is refreshed as it opens.
Press Ctrl/⌘+K again, Esc, or click outside it to close it.
Go to a screen
With nothing typed, the palette lists these commands, then your models:
| Command | Hint | Opens |
|---|---|---|
| Go to Home | Dashboard | Home |
| Go to Model Library | Browse all models | Model Library |
| New model… | Describe your business, or import a file | The New Model window |
| Go to Workspaces | Saved analysis canvases | Workspaces |
| Go to Scenarios | What-ifs on the open model | The open model's Scenarios. With no model open it's greyed out and reads Open a model first. |
| Go to Workflows | Recipes and their runs | Workflows |
| Go to Organization | — | The Organization screen |
| Go to Review Queue | — | The Review Queue |
Commands also match a few other words. canvas finds Go to Workspaces, runs and approvals find Go to Workflows, and import and spreadsheet find New model….
There's no command for Datasets; use the rail.
Open a model
Every model you can open is a command too. The hint says which tier it's in: Organizational · open model home or Personal · open model home. Pick one to open its Overview.
Typing matches the model's name, description, tags and domain. A model that's still importing is greyed out and can't be picked.
Search
Type any part of a word. Matches near the start of a name, or at the start of a word, rank first.
With nothing found, the palette says "No matches. Try a model name, a tag, or a screen."
Use the keyboard
| Key | Does |
|---|---|
| ↑ ↓ | Move the highlight. Hovering a row moves it too. |
| Enter | Run the highlighted command. |
| Esc | Close the palette. |
Every keyboard shortcut
eode has one global shortcut, Ctrl/⌘+K. Everything else works on one screen or in one box. "Mod" means Ctrl on Windows and Linux, ⌘ on macOS.
Anywhere
| Keys | Does | More |
|---|---|---|
| Mod+K | Open or close the command palette | This page |
| Esc | Close Page settings, the model menu, Help & support, or the palette | Page settings |
RIA console
| Keys | Does | More |
|---|---|---|
| Enter or Space on the diamond | Open the console with the cursor in the message box | RIA console |
| Enter | Send. On Scenarios, create a what-if from the message | RIA console |
| Shift+Enter | New line | RIA console |
| Esc | Close the console back to the diamond | RIA console |
Building a model
| Keys | Does | More |
|---|---|---|
| Enter or Space on a step-rail row | Jump to that step or question | New model |
| Mod+Enter in a written answer | Same as Next | Describe your business |
| Enter in Type your own answer | Save the answer. Shift+Enter starts a new line | Load your data |
Models
| Keys | Does | More |
|---|---|---|
| Enter / Esc while renaming | Save / cancel. Works for a model (on its Overview and in the Library) and a scenario | Model home, Model library, Scenarios |
| Enter in Add a requirement | Add it | Change a model |
| Esc in a fullscreen diagram | Close the inspector, then leave fullscreen | Topology |
Data grids
| Keys | Does | More |
|---|---|---|
| Arrows, Shift+arrows, Tab | Move; extend the selection; move right | Edit data |
| Enter / Esc | Edit a cell, commit / cancel | Edit data |
| Delete or Backspace | Clear the selected editable cells | Edit data |
| Mod+A, Mod+C, Mod+V | Select all, copy, paste | Edit data |
| Mod+D / Mod+R | Fill down / fill right | Edit data |
| Mod+Z; Mod+Shift+Z or Mod+Y | Undo; redo | Edit data, Edit a dataset |
| Mod+F | Find and replace in a dataset | Edit a dataset |
| Mod+S | Save a dataset | Edit a dataset |
| Esc, ↓ in Filter resources | Clear the filter (twice to leave the box); move into the list | Datasets |
| ↑ ↓ Home End Esc in a dataset's sort menu | Move through the choices; close | Datasets |
| Esc in Import Data | Close the window, unless an import is running | Import data |
Workspaces and workflows
| Keys | Does | More |
|---|---|---|
| Mod+Enter | Submit the box behind Have RIA build it, Ask RIA in Compose data query, or Ask RIA in Describe a widget | Workspaces |
| Esc | Leave fullscreen (a workspace, a single tile, or a workflow stage) | Workspaces, Widgets, Workflow runs |
| ← → in a fullscreen workspace | Page through the model's workspaces | Workspaces |
| ← → on a focused panel edge | Resize the panel 16 pixels (48 with Shift) | Workspaces |
| Shift-click or Mod-click a bar | Add a value to the highlight, or take it out | Widgets |
| Enter in Add to thread… | Post to a Live commentary tile | Widgets |
Help & support
| Keys | Does | More |
|---|---|---|
| Mod+Enter | Send a reply to support | Help & support |
Limits
- Up to 12 results at a time, with or without a search.
- Matching is on the letters you type, in order; a typo finds nothing.
